Inconel 600 Tube Fittings

Home > Inconel > Inconel 600 Tube Fittings

Inconel 600 Tube Fittings manufactured and supplied from Hanoi, Vietnam are engineered for high-performance connections in piping and instrumentation systems exposed to high temperatures and corrosive environments. Made from premium Inconel 600 alloy, these fittings offer exceptional resistance to oxidation, chemical attack, and stress corrosion cracking, ensuring long-lasting, leak-free connections. Manufacturers in Hanoi follow strict quality control and precision machining standards to deliver reliable and durable fittings. Inconel 600 Tube Fittings are widely used in chemical processing, petrochemical, oil & gas, power generation, and marine industries, providing safe, efficient, and maintenance-free service in extreme operating conditions.

Inconel 600 Instrumentation Tube Fittings Supplier in Da Nang, Inconel 600 Double Ferrule Tube Fittings Price List in Hanoi, UNS N06600 Instrumentation Tube Fittings Manufacturer in Hue, Inconel 600 Single Ferrule Fittings In Ho Chi Minh, Inconel 600 Ferrule Fittings Exporter in Hanoi, Inconel 600 Instrumentation Fittings Manufacturer in Sapa, Inconel 600 Compression Tube Fittings in Da Nang, Vietnam.

Inconel 600 Tube Fittings are manufactured from UNS N06600 alloy. Typical chemical composition includes Nickel (72% min), Chromium (14–17%), Iron (6–10%), Manganese (1% max), Silicon (0.5% max), and Carbon (0.15% max). This composition ensures excellent high-temperature strength, corrosion resistance, and oxidation protection. Mechanically, these fittings exhibit high tensile and yield strength, superior toughness, and stable performance under high-pressure and high-temperature conditions, making them ideal for critical industrial systems where durability and chemical resistance are essential.

Inconel 600 Tube Fittings Specifications

Material Test Certificates (MTC) for Tube Fitting as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175
Specifications	ASTM B366 / ASME SB366
Size	1/16 in. to 2 in. & 2mm to 50 mm.
Dimensional Range	1/16 to 2 inches (imperial); 2 to 50 mm (metric)
Working Pressures	Upto 2000 to 6000 PSI
Thread Type	NPT – ASME B1.20.1, SAE AS71051 \| ISO/BSP Parallel – ISO 228 \| ISO/BSP Tapered – ISO 7, BS EN 10226-1 \| SAE (Unified) – ASME B1.1
End Connections	NPT, ISO/BP, SAE/MS, AN, weld ends, port connectors, sanitary flanges, tube adapters
Types	Tube to Union, Tube to Male, Tube to Female, Instrument Pipe Fittings, Accessories
Equivalent To	SWAGELOK, PARKER, DK-LOK, HOKE
Max Working Pressure	8MPa \| 1200psi Depending on The Tubing Material
Working Temperature	-40°C—250°C \| -40°F—482°F Depending on The Tubing Material
Configurations	Straights, elbows, tees, crosses, caps, plugs, nuts and ferrules Chromatograph and Column End
Tube Fitting uses & application	Compression tube fitting to connect two imperial tubes (or fractional tubes), two metric tubes or, also, the connection of a metric tube at one end and a fractional/imperial tube at the other end in Petroleum, Power, Chemical, Construction, Gas, Metallurgy, Shipbuilding etc Tube Fittings useful for their extreme temperature and pressure capabilities for high/low temperatures applications, and their compatibility with aggressive fluids, compression fittings can be seen in systems varying from gas lines in refineries, plumbing etc.

Inconel 600 Tube Fittings Chemical Composition

Grade	C	Mn	Si	S	Cu	Fe	Ni	Cr
Inconel 600	0.15 max	1.00 max	0.50 max	0.015 max	0.50 max	6.00 – 10.00	72.00 min	14.00 – 17.00

Inconel 600 Tube Fittings Mechanical Properties

Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
8.47 g/cm3	1413 °C (2580 °F)	655 MPa, 95000 psi	310 MPa, 45000 psi	45 %

Types of Inconel 600 Tube Fittings

Inconel 600 Tube Fittings Equivalent Grades

STANDARD	UNS	WNR.	AFNOR	EN	JIS	BS	GOST	OR
Inconel 600	N06600	2.4816	NC15FE11M	NiCr15Fe	NCF 600	NA 13	МНЖМц 28-2,5-1,5	ЭИ868

Inconel 600 Instrumentation Tube Fittings Price in Da Nang, Inconel 600 Male Branch Tee Supplier in Hanoi, Inconel 600 Bulk Head Female Connector Manufacturer in Hue, Inconel 600 Single Ferrule Tube Fittings Price in Ho Chi Minh, Inconel 600 Male Run Tee Supplier And Manufacturer in Sapa, Inconel 600 Male Elbow In Da Nang, Vietnam.

Largest Manufacturer and Supplier of Inconel 600 Tube Fittings in Da Nang, Vietnam

Top Inconel 600 Tube Fittings Manufacturing Company in Da Nang At Moong Tube Fittings, we are proud to be the largest supplier, manufacturer, and exporter of Inconel 600 Tube Fittings in Da Nang, Vietnam. Our cutting-edge solutions cater to all your piping needs. With state-of-the-art production facilities strategically located in the Vietnam, we maintain a vast inventory of over 16,000 tons of premium-quality materials, ensuring we have the stock readily available to meet your demands.

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Inconel 600 Tube Fittings Uses

Inconel 600 tube fittings are widely used in applications requiring excellent abrasion and heat resistance. They are ideal for chemical plants, where acids, alkalis and chlorides are handled effectively. In wind space and electricity generation, these materials withstand extreme temperatures, making them suitable for gas turbines, heat exchangers and reactors. Inconel 600 fittings are also used in nuclear plants, providing resistance to extreme radiation and high-pressure environments. Their durability and excellent performance make them reliable for rugged applications under severe corrosive conditions.
