Moong Tubefittings is a trusted manufacturer and supplier of high-performance alloy fittings based in Hanoi, Vietnam. The company specializes in precision-engineered products for demanding industries such as chemical processing, oil and gas, petrochemical, and power generation. With a strong focus on material quality and international standards, Moong Tubefittings offers Hastelloy BSP / NPT Fittings designed for severe corrosion and high-temperature environments. These fittings provide reliable, leak-free threaded connections and long service life in applications where standard materials are inadequate.

Hastelloy C276 NPT 45 Deg Street Elbow Fittings Manufacturer Da Nang, ASTM B564 C276 Hastelloy Alloy BSP Street Union Dealer Hanoi, Hastelloy Alloy BSP Threaded Bushing Supplier Hue, ASME SB564 Hastelloy Alloy C22 BSP Elbows Exporter In Ho Chi Minh, Alloy C22 BSP 90 Deg. Street Elbow Sapa, ASME B16.11 Hastelloy Alloy BSP Crosses Da Nang, Vietnam.

Hastelloy BSP / NPT Fittings are manufactured from nickel-based Hastelloy alloys containing chromium, molybdenum, and iron. This composition offers exceptional resistance to pitting, crevice corrosion, and stress corrosion cracking. The material provides high tensile strength, excellent toughness, and stability at elevated temperatures. Precision threading ensures secure engagement, while the alloy’s mechanical strength allows reliable performance under high pressure and aggressive chemical exposure.

Hastelloy BSP / NPT Fittings Specifications

Specifications: ASTM B564/ ASME SB564
Size: 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Dimensions : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Types : Socketweld Fittings, Screwed-Threaded Fittings
Pressure Rating: Threaded End-2000lb/ 3000lb/ 6000lbs /
Socket-weld End-3000/ 6000/ 9000lbs
Thread: NPT, BSPT, BSPP

Hastelloy BSP / NPT Fittings Chemical Composition

Hastelloy BSP / NPT	Ni	C	Mo	Mn	Si	Fe	P	S	Co	Cr
Hastelloy BSP / NPT	Balance	0.010 max	15.00 – 17.00	1.00 max	0.08 max	4.00 – 7.00	0.04 max	0.03 max	2.5 max	14.50 – 16.50

Hastelloy BSP / NPT Fittings Mechanical Properties

Elongation	Density	Yield Strength (0.2%Offset)	Melting Point	Tensile Strength
40 %	8.89 g/cm3	Psi – 52,000 , MPa – 355	1370 °C (2500 °F)	Psi – 1,15,000 , MPa – 790

Types of Hastelloy BSP / NPT Fittings

Equivalent Grades of Hastelloy BSP / NPT Fittings

STANDARD	WERKSTOFF NR.	UNS	JIS	GOST	EN	OR
Hastelloy BSP C276	2.4819	N10276	NW 0276	ХН65МВУ	NiMo16Cr15W	ЭП760
Hastelloy NPT C22	2.4602	N06022	NW 6022	–	NiCr21Mo14W	–

ASME SB564 Hastelloy Alloy C276 NPT Screwed Elbow Price in Da Nang, Hastelloy Alloy C276 BSP 45 Deg Street Elbow Manufacturer Supplier in Hanoi, Hastelloy Alloy C276 NPT 90 Degree Forged Elbow Manufacturer in Hue, Hastelloy NPT 45 Degree Forged Elbow Fittings Price in Ho Chi Minh, ANSI B16.11 Hastelloy C276 BSP / NPT Elbow Supplier And Manufacturer in Sapa, Hastelloy C22 NPT Elbow In Da Nang, Vietnam.

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Manufacturer and Supplier of Hastelloy BSP / NPT Fittings in Da Nang, Vietnam

At Moong Tube Fittings, we are proud to be the largest supplier, manufacturer, and exporter of Hastelloy BSP / NPT Fittings in Da Nang, Vietnam. Our cutting-edge solutions cater to all your piping needs. With state-of-the-art production facilities strategically located in the Vietnam, we maintain a vast inventory of over 16,000 tons of premium-quality materials, ensuring we have the stock readily available to meet your demands.

Hastelloy BSP / NPT Fittings Uses

Hastelloy BSP / NPT Fittings are widely used in highly corrosive and high-temperature applications. Common industries include chemical and petrochemical plants, oil and gas processing, offshore installations, pharmaceuticals, and pollution control systems. They are ideal for handling strong acids, chlorides, solvents, and mixed chemical streams. These fittings are commonly used in pipelines, instrumentation connections, and process equipment where leak-free threaded joints and corrosion resistance are critical. Their durability and reliability make them suitable for the most demanding industrial environments.
