Duplex Stainless Steel Condensate Pots

Home > Duplex Steel> Duplex Stainless Steel Condensate Pots

Moong Tubefittings is a trusted manufacturer and supplier of high-performance instrumentation accessories and piping components based in Hanoi, Vietnam. The company serves critical industries such as oil and gas, offshore, petrochemical, and power generation with products that meet international quality standards. Known for precision engineering and material excellence, Moong Tubefittings offers Super Duplex Stainless Steel Condensate Pots designed for extreme pressure and highly corrosive environments. These condensate pots ensure accurate pressure measurement, equipment protection, and long-term reliability in demanding steam and process applications.

Duplex Stainless Steel Type A Condensate Pots with 2 Ports Manufacturer Da Nang, Duplex Stainless Steel Type B Condensate Pot with Red Oxide Coated Dealer Hanoi, S31803 Duplex Stainless Steel Condensate Pots Type C Supplier Hue, 2205 Duplex Stainless Steel Type A Condensate Pot Exporter In Ho Chi Minh, Duplex Stainless Steel Type B Condensate Pots with 3 Ports Manufacturer Sapa, Duplex Stainless Steel Type C Condensate Pot with Galvanized Plating Da Nang, Vietnam.

Super Duplex Stainless Steel Condensate Pots are manufactured from super duplex alloys containing high chromium, molybdenum, and nitrogen. This composition provides exceptional resistance to pitting, crevice corrosion, and stress corrosion cracking. The material offers very high tensile and yield strength, excellent fatigue resistance, and outstanding performance under high pressure and temperature conditions. These condensate pots maintain structural integrity, toughness, and corrosion resistance in aggressive and marine environments.

Duplex Stainless Steel Condensate Pots Specifications

Standard : DIN, ASTM, BS and all International Standards.
Number of Ports : 2 ports upto 8 ports, refer to the section below for arrangements.
Working Pressure : 6000 PSIG(41.34 MPa).
Pressure Rating : 1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI.
Header Inlet : 1” Female Bsp or Npt threaded to ASME B16.1 or Flanged inlet optional.
Header Outlet/drain : None / or ¼”Male Bsp or Npt threaded to ASME B16.1 or 150# cast fitting.
Pipe size : 2″, 3″, 4″, 5”, 6” and larger size upon request.
Pipe Schedule : 40, 80, 160, XX seamless pipe.
Total Length : Pipe length 8″,10″,12″ and larger length upon request.
Thread Connections : NPT as per ANSI B1.20.1,Socket weld as per ANSI B16.11, Butt weld as per ANSI B16.9.

Sizing Of Duplex Stainless Steel Condensate Pots

P NPT – F	Capacity (Internal Vol.0)cm 3±5%	Pressure Rating PSIG	T mm	L mm	B mm
1/4”	150	1800	2.05	135	50.08
1/4”	300	1800	2.05	225	50.08
1/4”	400	1800	2.05	290	50.08
1/4”	500	1800	2.05	350	50.08
1/4”	1000	1800	4.06	275	88.09
1/4”	2250	1800	5.02	435	120
1/4”	3785	1800	5.02	680	120
1/2”	1000	1800	4.06	275	88.09
1/2”	2250	1800	5.02	435	102
1/2”	3785	1800	5.02	680	102
3/4”	1000	1800	4.06	275	88.09
3/4”	2250	1800	5.02	435	102
3/4”	3785	1800	5.02	680	102

Types of Duplex Stainless Steel Condensate Pots

Duplex Stainless Steel Type A Condensate Pot with Zinc Plating Price in Da Nang, DSS Type B Condensate Pots Supplier in Hanoi, 2205 Duplex Stainless Steel Type C Condensate Pot Manufacturer in Hue, Duplex Stainless Steel Type A Condensate Pot with Galvanized Plating Manufacturer & Price in Ho Chi Minh, Duplex Stainless Steel Condensate Pot Type B Supplier in Sapa, Duplex Stainless Steel Type C Condensate Pot with Red Oxide Coated In Da Nang, Vietnam.

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Manufacturer and Supplier of Duplex Stainless Steel Condensate Pots in Da Nang, Vietnam

At Moong Tube Fittings, We are proud to be the largest supplier, manufacturer, and exporter of Duplex Stainless Steel Condensate Pots in Da Nang, Vietnam Our cutting-edge solutions cater to all your piping needs. With state-of-the-art production facilities strategically located in the Vietnam, we maintain a vast inventory of over 16,000 tons of premium-quality materials, ensuring we have the stock readily available to meet your demands.

Duplex Stainless Steel Condensate Pots Uses

Super Duplex Stainless Steel Condensate Pots are widely used in severe service conditions where standard materials fail. Common applications include offshore oil and gas platforms, subsea systems, refineries, chemical processing plants, power generation units, and desalination facilities. They are used to collect condensate and protect pressure gauges and transmitters from direct steam contact. Due to their superior strength and corrosion resistance, these condensate pots are ideal for high-pressure, high-temperature, and chloride-rich environments requiring long-term reliability.
